I have been working on creating some new login templates and adapting some other. Download ultimate breaks beats rapidshare free premium. With instructions on how to install them for beginners:.

Important note: This solution requires a Hotspot Operator Account at HotSpotSystem.com. You can create an Operator Account. If you would like to see what features you will be able to use with our solutions,. If you already have an Operator Account, then read on. Before starting, reset your router. If you see a message about press Remove configuration.

Template

You need to setup your Mikrotik router by using Winbox. Winbox is the graphical user interface for configuring the Mikrotik Router OS. First we need to define the first port for WAN connection so the router will connect to the internet via another router with DHCP. In winbox click IP > DHCP Client and Add DHCP Client to port ether1 2.

Let's add the hotspot service to wlan Click IP > HotSpot and the hotspot Setup box, choose wlan1 as hotspot interface. You can accept default values but choose none for certificate. Leave the IP as it is (10.5.50.x). If you change this IP, the LOGIN and LOGOUT links will not work on your splash page. The router should be placed in ap bridge mode. Click interface, double click wlan1, click Mode: and select ap bridge And make sure the frequency is set to 2.4 b/G.

You need to add our radius server as authentication and accounting server. In the hotspot profiles (IP > HotSpot > Profiles) choose your hotspot profile and click the radius tab, check allow radius. Then click the login tab and de-select cookie, allow https, http pap and chap. You need to define our radius server. Click Radius and the + sign to add our radius server.

Click Services > Hotspot, enter radius address: radius.hotspotsystem.com, Secret: hotsys123 Check the box next to hotspot Modify the timeout value to 3000 6. You need to add the secondary radius server. Click Radius and the + sign.

Click Services > Hotspot, enter radius Address: radius2.hotspotsystem.com, Secret: hotsys123 Check the box next to hotspot Modify the timeout value to 3000 7. We have to allow certain sites and servers for non authenticated users otherwise they can't buy access. In the section IP > HotSpot > Walled Garden, click on + sign and add the following domains to Dst. Host one by one: *.hotspotsystem.com *.worldpay.com *.paypal.com *.paypalobjects.com *.paypal-metrics.com *.altfarm.mediaplex.com *.akamaiedge.net paypal.112.2O7.net *.moneybookers.com *.adyen.com *.directebanking.com *.paysafecard.com betalen.rabobank.nl ideal.ing.nl ideal.abnamro.nl.

For Hotspot FREE SOCIAL locations: you need to add several domains/hosts to the allowed field in order to allow users to log in to there favorite social site. Please to add these domains/hosts to the whitelist. Cek token listrik pln. Then in the section IP > HotSpot > Walled Garden > IP List add the following IPs to Dst.

Address one by one (if your Mikrotik doesn't allow netmask values (.0/24) you can skip the netmask value): 194.149.46.0/24 198.241.128.0/17 66.211.128.0/17 216.113.128.0/17 70.42.128.0/17 128.242.125.0/24 216.52.17.0/24 62.249.232.74 155.136.68.77 66.4.128.0/17 66.211.128.0/17 66.235.128.0/17 88.221.136.146 195.228.254.149 195.228.254.152 203.211.140.157 203.211.150.204 82.199.90.136/29 82.199.90.160/27 91.212.42.0/24 Then in the section IP > HotSpot > Walled Garden > IP List add the following IPs to Dst. Host: www.paypal.com 8. You need to syncronize the router's time with our server. Click on System > NTP Client. Enter primary and secondary NTP servers.
